| Specifications | MS-H S10 |
|---|---|
|
Work Plate Dimension [W x D]
|
180 x 450 mm |
|
Work Plate Material
|
Stainless Steel Covered with silicone cushion |
|
Motor Type
|
Brushless DC Motor |
|
Stirring Positions |
10 |
|
Max. Stiring Quantity (H20) |
0.4 L x 10 |
|
Max. Magnetic Bar [Length] |
40 mm |
|
Speed Range |
0 – 1100 rpm |
|
Speed Display |
Scale |
|
Temperature Display |
Scale |
|
Control Accuracy of Sensor |
+- 20 rpm |
|
Heating Temperature Range |
Room Temp. – 120 °C |
|
Heating Liquid Temperature Control Accuracy |
+- 1°C(<100 °C)
+- 1 %(>100 °C) |
|
Overheating Temperature Protection |
140 °C |
|
Temperature Display Accuracy |
+- 0.1 °C |
|
External Temperature Sensor |
PT 1000(Acuracy +-02.°C) |
|
“Hot” Warning |
50 °C |
|
Data Connector |
— |
|
Protection Class |
IP20 |
|
Timer Function |
— |
|
Motor Rating Input |
12W |
|
Motor Rating Output |
4W |
|
Power |
490W |
|
Heanitg Output |
470W |
|
Voltage Frequency |
100-120/200-240V 50/60Hz |
|
Dimension [WxDxH] |
182 × 622 × 65 mm |
|
Weight |
3.2 kg |
|
Permissible Ambient Temperature and Humidity |
5- 40 ºC 80% RH |
