| Specifications | MS-H-PRO T |
|---|---|
|
Work Plate Dimension [W x D]
|
0 135 mm (5 inch) |
|
Work Plate Material
|
Stainless Steel Cover with ceramic coating |
|
Motor Type
|
Brushless DC Motor |
|
Stirring Positions |
1 |
|
Max. Stiring Quantity (H20) |
20 L |
|
Max. Magnetic Bar [Length] |
80 mm |
|
Speed Range |
100 – 1500 rpm resolution +- 1rpm |
|
Speed Display |
LCD |
|
Temperature Display |
LCD |
|
Heating Temperature Range |
Room Temp. -340 °C Increment 1 C° |
|
Heating Liquid Temperature Control Accuracy |
+- 1°C(<100 °C)
+- 1 %(>100 °C) |
|
Overheating Temperature Protection |
420 °C |
|
Temperature Display Accuracy |
+- 0.1 °C |
|
External Temperature Sensor |
PT 1000(Acuracy +-02.°C) |
|
“Hot” Warning |
50 °C |
|
Data Connector |
RS232 |
|
Protection Class |
IP21 |
|
Timer Function |
1min to 99h 59min |
|
Motor Rating Input |
18W |
|
Motor Rating Output |
10W |
|
Power |
550W |
|
Heanitg Output |
500W |
|
Voltage Frequency |
100-120/200-240V 50/60Hz |
|
Dimension [WxDxH] |
160 x 280 x 10 mm |
|
Weight |
2.8 kg |
|
Permissible Ambient Temperature and Humidity |
5- 40 ºC 80% RH |
Magnetic Hotplate Stirrer MS-H Pro +
Request Price
Magnetic Hotplate Stirrer MS-H S
Request Price
Magnetic Hotplate Stirrer MS-H Pro T
Request Price
- Brushless DC motor is maintenance free and explosion-proof
- Digital temperature control with max. temperature at 340°C
- Digital speed control with max. speed up to 1500rpm
- Max. stirring quantity of H2O at 20L
- Safety circuits provide overheating protection
- The “HOT” warning will flash if the plate temperature is above 50°C even when the hotplate is turned off
- Wide range timer function from 1min to 99h59min
- High-resolution LCD display shows actual temperatures，speed and time
- External temperature control is possible by connecting the temperature sensor(PT 1000) with accuracy at ±0.2°C
- Stainless steel work plate with ceramic coating provides good chemical-resistant performance
- Remote function provides PC control and data transmission
- A wide variety of accessories are available
